Senmei's SM-FZ-B automatic paper slitting rewinding machine slits and rewinds jumbo rolls of kraft paper, label stock, and laminated face stock upstream of paper tube and can production lines. Mechanical-arm roll handling, universal bearings, and frequency-controlled speed deliver clean edges and tight, even rewound rolls.
The SM-FZ-B takes parent rolls up to 1600 mm wide and 1200 mm in diameter and slits them into finished rolls from 35 mm upward, at web speeds of 1–200 m/min. It is engineered for heavyweight stocks such as kraft paper and processes paper weights from 80 to 600 g without re-tooling.
A mechanical arm grips and adjusts the large paper roll, cutting labor requirements at the unwind station. Rewound rolls separate automatically so lanes never tangle, and the slit edges leave the machine smooth and polished — ready to feed directly into the SM1600-Q paper core cutting or SM600-W outer coiling platforms downstream.
| Model | SM-FZ-B automatic paper slitter rewinder |
|---|---|
| Brand | Senmei Packaging Machinery |
| Original paper width | 1600 mm |
| Original paper diameter | 1200 mm |
| Rewind diameter | Confirmed per inquiry |
| Slitting width | >35 mm |
| Original paper weight | 80–600 g |
| Number of blades | 18 pcs |
| Slitting speed | 1–200 m/min |
| Speed control | Frequency control |
| Main power supply | 11 kW |
| Total weight | 4000 kg |
Design details that keep slit quality and rewound roll density consistent, shift after shift.
Rewind diameter, target slit widths, web-guide accuracy, and pricing are confirmed per inquiry. Contact Barclay Liu at +86 131 7320 5213 with your paper stock grade, parent roll dimensions, target slit width, and downstream machine list, and the Senmei engineering team will respond with a configuration and lead time.
Senmei ships standard slitter and rewinder configurations from the Jiaozhou factory; lead time and commissioning scope confirmed per inquiry.
| HS Code | 8441.80 (other machinery for making up paper pulp, paper or paperboard) |
|---|---|
| Minimum order quantity (MOQ) | 1 unit |
| Lead time | 30–60 working days after deposit (confirmed per inquiry) |
| Payment terms | T/T 30% deposit + 70% balance after factory acceptance test; L/C at sight for large orders |
| Incoterms | FOB Qingdao (default) · CIF · CFR · DAP (door-to-door) |
| Packaging | Fumigation-free wooden case, anti-rust film, desiccant, foam-padded impact points; one standard machine per 20'GP |
| Loading port | Qingdao Port, Shandong Province, China |
| Country of origin | China |
| Certifications | CE marking (per shipment), ISO 9001 (manufacturer) |
| Warranty | 12 months limited on main components; wear parts excluded |
| Spare parts availability | 5 years from shipment date |
| Installation & training | One-for-one on-site engineer dispatch (quoted separately); remote video support included free first year |
| Documentation | Commercial invoice, packing list, certificate of origin (Form A / E / F), CE declaration, fumigation certificate |
For accurate FOB pricing, CIF quote to your destination port, and door-to-door delivery to your facility, contact Senmei with your destination country and tube specifications. Reply within 24 hours on business days via WhatsApp or email.
Send Senmei your parent roll stock, slit width, target output, and downstream machine list. The engineering team will come back with a configuration proposal.
These Senmei platforms integrate with the SM-FZ-B on a continuous stock-to-tube workflow.
